Vertical GaN and SiC Power Devices
This unique new resource provides a comparative introduction to vertical Gallium Nitride (GaN) and Silicon Carbide (SiC) power devices using real commercial device data, computer, and physical models. This book uses commercial examples from recent years and presents the design features of various GaN and SiC power components and devices. Vertical verses lateral power semiconductor devices are explored, including those based on wide bandgap materials. The abstract concepts of solid state physics as they relate to solid state devices are explained with particular emphasis on power solid state devices. Details about the effects of photon recycling are presented, including an explanation of the phenomenon of the family tree of photon-recycling. This book offers in-depth coverage of bulk crystal growth of GaN, including hydride vapor-phase epitaxial (HVPE) growth, high-pressure nitrogen solution growth, sodium-flux growth, ammonothermal growth, and sublimation growth of SiC.
eBook
Electronic Properties of Group-III Nitride Semiconductors and Device Structures Probed by THz Optical Hall Effect
Group-III nitrides have transformed solid-state lighting and are strategically positioned to revolutionize high-power and high-frequency electronics. To drive this development forward, a deep understanding of fundamental material properties, such as charge carrier behavior, is essential and can also unveil new and unforeseen applications. This underscores the necessity for novel characterization tools to study group-III nitride materials and devices. The optical Hall effect (OHE) emerges as a contactless method for exploring the transport and electronic properties of semiconductor materials, simultaneously offering insights into their dielectric function. This non-destructive technique employs spectroscopic ellipsometry at long wavelengths in the presence of a magnetic field and provides quantitative information on the charge carrier density, sign, mobility, and effective mass of individual layers in multilayer structures and bulk materials. In this paper, we explore the use of terahertz (THz) OHE to study the charge carrier properties in group-III nitride heterostructures and bulk material. Examples include graded AlGaN channel high-electron-mobility transistor (HEMT) structures for high-linearity devices, highlighting the different grading profiles and their impact on the two-dimensional electron gas (2DEG) properties. Next, we demonstrate the sensitivity of the THz OHE to distinguish the 2DEG anisotropic mobility parameters in N-polar GaN/AlGaN HEMTs and show that this anisotropy is induced by the step-like surface morphology. Finally, we present the temperature-dependent results on the charge carrier properties of 2DEG and bulk electrons in GaN with a focus on the effective mass parameter and review the effective mass parameters reported in the literature. These studies showcase the capabilities of the THz OHE for advancing the understanding and development of group-III materials and devices.
Journal Article
Review of Recent Progress on Vertical GaN-Based PN Diodes
As a representative wide bandgap semiconductor material, gallium nitride (GaN) has attracted increasing attention because of its superior material properties (e.g., high electron mobility, high electron saturation velocity, and critical electric field). Vertical GaN devices have been investigated, are regarded as one of the most promising candidates for power electronics application, and are characterized by the capacity for high voltage, high current, and high breakdown voltage. Among those devices, vertical GaN-based PN junction diode (PND) has been considerably investigated and shows great performance progress on the basis of high epitaxy quality and device structure design. However, its device epitaxy quality requires further improvement. In terms of device electric performance, the electrical field crowding effect at the device edge is an urgent issue, which results in premature breakdown and limits the releasing superiorities of the GaN material, but is currently alleviated by edge termination. This review emphasizes the advances in material epitaxial growth and edge terminal techniques, followed by the exploration of the current GaN developments and potential advantages over silicon carbon (SiC) for materials and devices, the differences between GaN Schottky barrier diodes (SBDs) and PNDs as regards mechanisms and features, and the advantages of vertical devices over their lateral counterparts. Then, the review provides an outlook and reveals the design trend of vertical GaN PND utilized for a power system, including with an inchoate vertical GaN PND.
Journal Article
Wide Band Gap Devices and Their Application in Power Electronics
Power electronic systems have a great impact on modern society. Their applications target a more sustainable future by minimizing the negative impacts of industrialization on the environment, such as global warming effects and greenhouse gas emission. Power devices based on wide band gap (WBG) material have the potential to deliver a paradigm shift in regard to energy efficiency and working with respect to the devices based on mature silicon (Si). Gallium nitride (GaN) and silicon carbide (SiC) have been treated as one of the most promising WBG materials that allow the performance limits of matured Si switching devices to be significantly exceeded. WBG-based power devices enable fast switching with lower power losses at higher switching frequency and hence, allow the development of high power density and high efficiency power converters. This paper reviews popular SiC and GaN power devices, discusses the associated merits and challenges, and finally their applications in power electronics.
Journal Article
Photoelectrochemical water splitting using post-transition metal oxides for hydrogen production: a review
Dihydrogen (H
2
), commonly named ‘hydrogen,’ is considered as a promising renewable fuel that does not emit carbon dioxide upon combustion. Nonetheless, since hydrogen is actually mainly produced from fossil fuels, sustainable methods such as water splitting are required. For that, metal oxide semiconductors have been explored as photoelectrode materials. In particular, post-transition metal oxide semiconductors such as gallium, indium, tin, lead, and bismuth have drawn attention due to of their unique properties, e.g. resistance to photocorrosion. Here, we review the properties, synthesis and recent developments of post-transition metal oxide semiconductors for water splitting. Gallium nitride nanowall network enhances photocurrent density up to 28 mA/cm
2
. Alloys of gallium and indium, in the form of indium gallium nitride, show photocurrent density of 32 mA/cm
2
with strong photon absorption and exceptional corrosion resistance in aqueous solutions.
Journal Article
Temperature Field, Flow Field, and Temporal Fluctuations Thereof in Ammonothermal Growth of Bulk GaN—Transition from Dissolution Stage to Growth Stage Conditions
With the ammonothermal method, one of the most promising technologies for scalable, cost-effective production of bulk single crystals of the wide bandgap semiconductor GaN is investigated. Specifically, etch-back and growth conditions, as well as the transition from the former to the latter, are studied using a 2D axis symmetrical numerical model. In addition, experimental crystal growth results are analyzed in terms of etch-back and crystal growth rates as a function of vertical seed position. The numerical results of internal process conditions are discussed. Variations along the vertical axis of the autoclave are analyzed using both numerical and experimental data. During the transition from quasi-stable conditions of the dissolution stage (etch-back process) to quasi-stable conditions of the growth stage, significant temperature differences of 20 K to 70 K (depending on vertical position) occur temporarily between the crystals and the surrounding fluid. These lead to maximum rates of seed temperature change of 2.5 K/min to 1.2 K/min depending on vertical position. Based on temperature differences between seeds, fluid, and autoclave wall upon the end of the set temperature inversion process, deposition of GaN is expected to be favored on the bottom seed. The temporarily observed differences between the mean temperature of each crystal and its fluid surrounding diminish about 2 h after reaching constant set temperatures imposed at the outer autoclave wall, whereas approximately quasi-stable conditions are reached about 3 h after reaching constant set temperatures. Short-term fluctuations in temperature are mostly due to fluctuations in velocity magnitude, usually with only minor variations in the flow direction.
Journal Article
Effects of Thermal Boundary Resistance on Thermal Management of Gallium-Nitride-Based Semiconductor Devices: A Review
Wide-bandgap gallium nitride (GaN)-based semiconductors offer significant advantages over traditional Si-based semiconductors in terms of high-power and high-frequency operations. As it has superior properties, such as high operating temperatures, high-frequency operation, high breakdown electric field, and enhanced radiation resistance, GaN is applied in various fields, such as power electronic devices, renewable energy systems, light-emitting diodes, and radio frequency (RF) electronic devices. For example, GaN-based high-electron-mobility transistors (HEMTs) are used widely in various applications, such as 5G cellular networks, satellite communication, and radar systems. When a current flows through the transistor channels during operation, the self-heating effect (SHE) deriving from joule heat generation causes a significant increase in the temperature. Increases in the channel temperature reduce the carrier mobility and cause a shift in the threshold voltage, resulting in significant performance degradation. Moreover, temperature increases cause substantial lifetime reductions. Accordingly, GaN-based HEMTs are operated at a low power, although they have demonstrated high RF output power potential. The SHE is expected to be even more important in future advanced technology designs, such as gate-all-around field-effect transistor (GAAFET) and three-dimensional (3D) IC architectures. Materials with high thermal conductivities, such as silicon carbide (SiC) and diamond, are good candidates as substrates for heat dissipation in GaN-based semiconductors. However, the thermal boundary resistance (TBR) of the GaN/substrate interface is a bottleneck for heat dissipation. This bottleneck should be reduced optimally to enable full employment of the high thermal conductivity of the substrates. Here, we comprehensively review the experimental and simulation studies that report TBRs in GaN-on-SiC and GaN-on-diamond devices. The effects of the growth methods, growth conditions, integration methods, and interlayer structures on the TBR are summarized. This study provides guidelines for decreasing the TBR for thermal management in the design and implementation of GaN-based semiconductor devices.
Journal Article
The Influence of AlGaN Spacer Thickness on the Electrical Properties of InAlN/AlGaN/AlN/GaN Heterostructure
InAlN is particularly suitable for applications in high-power electronic devices because it has a higher polarization than traditional barrier layer materials and can achieve no lattice constant mismatch between GaN and InAlN. However, the InAlN epitaxial layer alloy disorder is difficult to improve, which will seriously affect the mobility of two-dimensional electron gas (2DEG) formed by InAlN/GaN heterostructures. In this paper, two groups of GaN-based heterostructures have been fabricated to study the influence of InAlN thickness and AlGaN thickness on the In0.17Al0.83N/Al0.23Ga0.77N/AlN/GaN heterostructure electrical properties. A wide range of 2DEG sheet density from 1.12 × 1013 to 1.92 × 1013 cm−2 was achieved while the mobility varied from 1064 to 1945 cm2/V s. Both the 2DEG mobility and the surface flatness improved a lot with the increase of the Al0.23Ga0.77N thickness. The heterostructure with 16 nm InAlN shows a higher electron mobility and 2DEG sheet density compared with that with 8 nm InAlN. In addition, there exists a proper thickness of AlGaN spacer to strike a balance between the 2DEG mobility and sheet density to achieve the lowest sheet resistance. The proper thickness is around 2–4 nm which will keep the sheet resistance in a low level.
Journal Article
A Short Review on Properties and Applications of Zinc Oxide Based Thin Films and Devices : ZnO as a promising material for applications in electronics, optoelectronics, biomedical and sensors
Zinc oxide has emerged as an attractive material for various applications in electronics, optoelectronics, biomedical and sensing. The large excitonic binding energy of 60 meV at room temperature as compared to 25 meV of gallium nitride, an III-V compound makes ZnO an efficient light
emitter in the ultraviolet (UV) spectral region and hence favourable for optoelectronic applications. The high conductivity and transparency of ZnO makes it important for applications like transparent conducting oxides (TCO) and thin-film transistors (TFT). In this paper, the optoelectronic,
electronic and other properties that make ZnO attractive for a variety of applications are discussed. Various applications of ZnO thin film and its devices such as light-emitting diodes (LED), UV sensors, biosensors, photodetectors and TFT that have been described by various research groups
are presented.
Journal Article
