Combining analytic theory and modern computer-aided designtechniques this volume will enable you to understand and designpower transfer networks and amplifiers in next generation radiofrequency (RF) and microwave communication systems.

This rigorous treatment of transmission lines presents all the essential concepts in a clear and straightforward manner. Key principles are demonstrated by numerous practical worked examples and illustrations, and complex mathematics is avoided throughout. Early chapters cover pulse propagation, sinusoidal waves and coupled lines, all set within the context of a simple lossless equivalent circuit. Later chapters then develop this basic model by demonstrating the derivation of circuit parameters, and the use of Maxwell's equations to extend this theory to major transmission lines. Finally, a discussion of photonic concepts and properties provides valuable insights into the fundamental physics underpinning transmission lines. Covering DC to optical frequencies, this accessible text is an invaluable resource for students, researchers and professionals in electrical, RF and microwave engineering.

Broadband Powerline Communications: Network Design covers the applications of broadband PLC systems in low-voltage supply networks, a promising candidate for the realization of cost effective solutions for \"last mile\" communications networks. There are many activities surrounding the development and application of PLC technology in the access area, particularly because of strong interest of new network providers after the deregulation of telecommunications market. Nowadays, there are no existing standards for broadband PLC networks, which use a frequency range up to 30 MHz. This book includes relevant and timely information regarding broadband PLC systems and especially PLC access networks and contributions to the design aspects of broadband PLC access systems and their network components. This book: Offers explanations on how broadband PLC networks are realized, what the important characteristics for the transmission on electrical power grids are, and which implementation solutions have been recently considered for the  realization of broadband PLC systems. Considers various system realizations, disturbance scenarios and their impact the transmission in PLC networks, electro-magnetic compatibility, applied modulation schemes, coding, and error handling methods. Pays particular attention to the specifics of the PLC MAC layer and its protocols, as well as the modelling and performance evaluation of broadband PLC networks.

Microstrip Lines I: Quasi-Static Analyses, Dispersion Models, and Measurements Microstrip Lines II: Fullwave Analyses, Design Considerations, and Compensation, Microstrip Discontinuities: Analysis, Characterization, and Coupled Microstrip Lines, Defected Ground Structure, Coplanar Lines: Coplanar Waveguide and Coplanar Strips, Metamaterials and Planar Transmission Lines, Substrate Integrated Waveguide, Numerical Simulation and Modeling

A much-needed primer on all aspects of transmission lines for electric and computer engineering graduatesMost of today’s electrical engineering and computer engineering graduates lack a critically important skill: the analysis of transmission lines. They need this basic knowledge in order to be able to design high-speed digital and high-frequency analog systems—and this problem will only get worse as the speeds and frequencies of these systems continue to increase. This important text is the remedy. It prepares readers for increasingly difficult design problems in today’s ever-changing high-speed digital world, focusing on signal integrity and crosstalk.Class-tested under the author’s expert guidance at Mercer University, the book starts by reviewing the fundamental concepts of waves, wavelength, time delay, and electrical dimensions, as well as the bandwidth of digital signals and its relation to the pulse rise/fall times. It then explains two-conductor transmission lines and designing for signal integrity, addressing the time-domain analysis of those transmission lines and the corresponding analysis in the frequency domain. The terminal voltages and currents of lines with various source waveforms and resistive terminations are computed by hand via wave tracing. This gives considerable insight into the general behavior of transmission lines in terms of forward- and backward-traveling waves and their reflections. The effect of line losses including skin effect in the line conductors and dielectric losses in the surrounding dielectric are increasingly becoming critical, and their detrimental effects are discussed.Next, the book repeats these topics for three-conductor lines in terms of the important detrimental effects of crosstalk between transmission lines, explaining the transmission-line equations for lossless lines, the important per-unit-length matrices of the inductance and capacitance of the lines, and the solution of three-conductor, lossless lines via mode decoupling. The final chapter concludes by investigating the effects of the line losses on the crosstalk of these three-conductor lines.Each chapter concludes with numerous problems for the reader to practice his/her understanding of the material. An Appendix contains a brief tutorial on SPICE (PSPICE), an important computational tool that is used extensively throughout the book. The included CD features several computer programs used and described in this book for computing the per-unit-length parameter matrices and a subcircuit model for three-conductor lines, as well as two MATLAB programs for computing the Fourier components of a digital waveform and two versions of PSPICE.This book is intended as a textbook for a senior/first-year graduate-level course in transmission lines in electrical engineering and computer engineering curricula. It is also essential for industry professionals as a compact review of transmission line fundamentals.

This book presents and discusses alternatives to ordinary transmission lines for the design and implementation of advanced RF/microwave components in planar technology. This book is devoted to the analysis, study and applications of artificial transmission lines mostly implemented by means of a host line conveniently modified (e.g., with modulation of transverse dimensions, with etched patterns in the metallic layers, etc.) or with reactive loading, in order to achieve novel device functionalities, superior performance, and/or reduced size. The author begins with an introductory chapter dedicated to the fundamentals of planar transmission lines. Chapter 2 is focused on artificial transmission lines based on periodic structures (including non-uniform transmission lines and reactively-loaded lines), and provides a comprehensive analysis of the coupled mode theory. Chapters 3 and 4 are dedicated to artificial transmission lines inspired by metamaterials, or based on metamaterial concepts. These chapters include the main practical implementations of such lines and their circuit models, and a wide overview of their RF/microwave applications (including passive and active circuits and antennas). Chapter 5 focuses on reconfigurable devices based on tunable artificial lines, and on non-linear transmission lines. The chapter also introduces several materials and components to achieve tuning, including diode varactors, RF-MEMS, ferroelectrics, and liquid crystals. Finally, Chapter 6 covers other advanced transmission lines and wave guiding structures, such as electroinductive-/magnetoinductive-wave lines, common-mode suppressed balanced lines, lattice-network artificial lines, and substrate integrated waveguides. Artificial Transmission Lines for RF and Microwave Applications provides an in-depth analysis and discussion of artificial transmission lines, including design guidelines that can be useful to researchers, engineers and students.

A conventional differential line (DL), commonly used on typical digital circuit boards for transmitting high-speed digital data, has fundamental limitations on the maximum signal bandwidth (~10 GHz), mainly due to signal skew, multiple line coupling, and EM interference. Therefore, to support super-high-speed digital data transmission, especially for beyond 5G communications, a practical high-performance transmission structure for digital signals is required. Balanced lines (BLs) can transmit the differential signals with multiple advantages of ultra-wide bandwidth, common-mode rejection, reduced crosstalk, phase recovery, and skew reduction, which enable super-high-speed transmission. In order to utilize the BLs in the DL-based digital circuit, connecting structures between a DL and BLs are required, but the DL-to-BL transition structures dominate the operating bandwidth and signal properties. Therefore, in this paper, properties, and design methods for two ultra-wideband DL-to-BL transitions, i.e., DL-to-CPS (coplanar stripline) and DL-to-PSL (parallel stripline) transitions, are presented. Both implemented DL-to-CPS and DL-to-PSL transitions provide high-quality performance up to 40 GHz or higher, significantly enhancing the frequency bandwidth for the transmission of digital signals while providing compatibility with the DL-based PCBs. The fabricated DL-to-CPS transition performs well from DC to 40 GHz with an insertion loss of less than 0.86 dB and a return loss of more than 10 dB, and the fabricated DL-to-PSL transition also provides good performance from DC to 40 GHz, with an insertion loss of less than 1.34 dB and a return loss of more than 10 dB. Therefore, the proposed DL-to-BL transitions can be applied to achieve super-high-speed digital data transmission with over 40 GHz bandwidth, which is more than four times the bandwidth of the DL, supporting over 200 Gbps of digital data transmission on PCBs for the next generation of advanced communications.

With the development of communication technology, the interference from passive intermodulation to the communication system has become increasingly severe. Locating the source of passive intermodulation and then repairing or replacing the device experiencing passive intermodulation is a reliable method. Therefore, this paper proposes a dual-frequency signal localization method based on the principle of phase ranging to accurately locate the passive intermodulation sources in RF cables. This method switches the test signal frequency to obtain the phase of passive intermodulation signals at different frequencies to localize the passive intermodulation source. This paper analyzes the principle of the passive intermodulation localization method based on dual-frequency signals, establishes a localization system for experiments, and finally, analyzes the experimental error to propose an optimization strategy. Through experimental verification, this method can stabilize the positioning error of a passive intermodulation source in a transmission line less than 0.06 m. Meanwhile, this method has high positioning accuracy and the advantages of slight computational complexity, fast positioning speed, and only a small number of requirements on hardware resources. It can work in communication scenarios like satellite and base stations, providing a new technical solution for localizing passive intermodulation interference sources in 5G and 6G communication systems.

In this work, compact extended ultra-wideband (UWB) Wilkinson power dividers (WPDs) using tapered transmission lines are analyzed, designed, and measured. Utilizing carefully designed tapered transmission sections results in widening the operational bandwidth and reducing the element dimensions. Analytical models and design procedures of simple and compact and equal and unequal UWB WPDs based on linearly tapered transmission lines are developed and outlined in this paper. Four different configurations of equal and unequal power dividers are designed and presented. The number and locations of the isolation resistors have a noticeable effect on extending the operational bandwidth of the dividers. The presented designs of the WPDs have superior performance over extended bandwidths. The simulation and experimental results are in very good agreement with good insertion and return loss, good matching, and isolation, over the extended UWB operational bandwidth from 3 GHz to 27 GHz.
