Unmasking chloride attack on the passive film of metals

Wu, B., Zhang, B., Du, K., Oguzie, E. E., Ma, X. L., Wang, J., Zhang, Y. C., Guo, X. W., Wang, Y. J., Chen, D.

2018

Overview

Nanometer-thick passive films on metals usually impart remarkable resistance to general corrosion but are susceptible to localized attack in certain aggressive media, leading to material failure with pronounced adverse economic and safety consequences. Over the past decades, several classic theories have been proposed and accepted, based on hypotheses and theoretical models, and oftentimes, not sufficiently nor directly corroborated by experimental evidence. Here we show experimental results on the structure of the passive film formed on a FeCr 15 Ni 15 single crystal in chloride-free and chloride-containing media. We use aberration-corrected transmission electron microscopy to directly capture the chloride ion accumulation at the metal/film interface, lattice expansion on the metal side, undulations at the interface, and structural inhomogeneity on the film side, most of which had previously been rejected by existing models. This work unmasks, at the atomic scale, the mechanism of chloride-induced passivity breakdown that is known to occur in various metallic materials. Collecting experimental evidence of chloride ion attack on protective passive metallic films due to corrosion remains challenging. Here, the authors show that the boundaries between nanocrystals and amorphous regions in the passive film ease chloride transport even as they do not coincide with areas of high chloride concentration.

• Publisher: Nature Publishing Group UK,Nature Publishing Group,Nature Portfolio
• Subject: 147/143 / 639/301/1023/1026 / 639/301/930/328 / 639/638/161/892 / Atomic structure / Chloride / Chloride ions / Chlorides / Corrosion resistance / Crystal structure / Humanities and Social Sciences / Inhomogeneity / Ion accumulation / Metals / multidisciplinary / Science / Science (multidisciplinary) / Single crystals / Thick films / Transmission electron microscopy / Uniform attack (corrosion)
